Guardian Towers

Featured Image:

Guardian Towers

Location of Project - City:
Abu Dhabi
Location of Project - Country:
United Arab Emirates
The Guardian Towers are two, seventeen-story residential and office towers sharing a common two-level podium, including four basement levels containing a car park.
Location of Project - City:
Abu Dhabi
Location of Project - Country:
United Arab Emirates
Project Type:
Residential
Completion Date:
2010
Size of Project (in m2):
53800
Scope of Work:
Structural Design
e.construct Services:
Structural Design
Credits
Clients:
Guardian Towers Real Estates
e.construct Clients:
Dyena Contracting Company WLL
Consultants:
GA Architects & Engineers
Contractors:
Dyena Contracting Company WLL

Special Feature of e.construct Service:
e.construct’s approach was to design the raft, while resisting the uplift forces without tension piles, by connecting the retaining wall to the temporary bracing system (diaphragm wall) through capping beam. The weight of the diaphragm wall acts as a permanent counterbalance force to resist the uplift forces.
